Linux : Monitoring And supervision with Zabbix

Posted on March 5, 2015

Here is some notes of my own Zabbix monitoring system installation (debian based). It has been done since a while now, but I never took the time to finalize this post. However, it can still be usefull as not much (nothing ?) has changed regarding activities to do…

Base Install

Server Part

apt-get install apache2 mysql snmp zabbix-agent zabbix-frontend-php zabbix-server-mysql

1	apt-get install apache2 mysql snmp zabbix-agent zabbix-frontend-php zabbix-server-mysql

Snmp is of course only usefull if you have things that support it (my administrable switch does)…

Then follow instruction on /usr/share/doc/zabbix-server-mysql/README.Debian

In /etc/zabbix/zabbix_server.conf,

I comment out “LogFile” to use Syslog as I centralise all my logs with rsyslog
I set Housekeeping to 24 (small home network with less than 10 servers)
LogSlowQuery=10

Enable zabbix-server in /etc/default/zabbix-server and launch it:

/etc/init.d/zabbix-server start

1	/etc/init.d/zabbix-server start

Make the admin console available through an alias in apache and restrict access to some IP addresses (vhost should work too) :

&lt;Directory /usr/share/zabbix&gt;
     Options FollowSymLinks
     AllowOverride None
     Order allow,deny
     Allow from a.b.c
&lt;/Directory&gt;

&lt;IfModule mod_alias.c&gt;
    Alias /zabbix /usr/share/zabbix
&lt;/IfModule&gt;

Options FollowSymLinks

AllowOverride None

Order allow,deny

Allow from a.b.c

</Directory>

Alias /zabbix /usr/share/zabbix

</IfModule>

Put this in sites-available instead (I prefer that over the conf directory, then activate the site (either a2ensite or simple ln -s) and finaly restart apache (apachectl graceful).

Then, go to https://<server>/zabbix and follow the instructions.
At the end of the procedure, download and copy the generated configuration file to /etc/zabbix and set restrictive permission on it (db password in clear text inside) :

chown root:www-data /etc/zabbix/zabbix_server.conf
chmow 640 /etc/zabbix/zabbix_server.conf

1 2	chown root:www-data /etc/zabbix/zabbix_server.conf chmow 640 /etc/zabbix/zabbix_server.conf

Be careful: you may need to increase the number of MySQL connections (max_connection parameter) if you already have other services that use it (zabbix server + Php front-end eat up at least 10 connections for a single user).

Also, mysqltunner can be very usefull to check MySQL settings.

Client Part (agent)

If all is up and running, zabbix-agent must be installed on all server that need to be monitored (apt-get install zabbix-agent). Then :

set hostname
set zabbix server ip
optionally comment out LogFile to use syslog (rsyslog in my case)
update /etc/hosts.allow (eg: zabbix_agentd:<zabbix server ip>)

Custom Monitoring

HTTPS Urls

if monitoring of https services fail, change the standard item from “net.tcp.service[https]” to “net.tcp.service[tcp,,443]”

Apache

You can find great bash scripts to monitor apache variables here : https://www.zabbix.org/wiki/Docs/howto/apache_monitoring_script

copy them on /usr/share/zabbix-scripts/ and give proper permissions

chmod 770 /usr/share/zabbix-scripts/apache_report.sh
chown zabbix /usr/share/zabbix-scripts/apache_report.sh

1 2	chmod 770 /usr/share/zabbix-scripts/apache_report.sh chown zabbix /usr/share/zabbix-scripts/apache_report.sh

Nginx

Example can be found here : http://www.badllama.com/content/monitor-nginx-zabbix

If you want max supported connection on your screens, add the following “userparameter” :

UserParameter=nginx.maxconnection[*],grep -o "worker_[[:alpha:]]*[[:blank:]]*[[:digit:]]*[[:blank:]]*;" $1 | tr -d '\n' | tr ';' ' ' | awk '{print $$2 * $$4}'

1	UserParameter=nginx.maxconnection[],grep -o "worker_[[:alpha:]][[:blank:]][[:digit:]][[:blank:]];" $1 \| tr -d '\n' \| tr ';' ' ' \| awk '{print $$2 $$4}'

In case it may help, my own Nginx template : zbx_export_templates

MySQL

see https://www.zabbix.com/forum/showthread.php?t=41659

Create a user for zabbix that is allowed to check MySQL processes. For example :

GRANT PROCESS ON * . * TO 'zabbix'@'localhost' IDENTIFIED BY '***' WITH MAX_QUERIES_PER_HOUR 0 MAX_CONNECTIONS_PER_HOUR 0 MAX_UPDATES_PER_HOUR 0 MAX_USER_CONNECTIONS 0 ;

1	GRANT PROCESS ON * . * TO 'zabbix'@'localhost' IDENTIFIED BY '***' WITH MAX_QUERIES_PER_HOUR 0 MAX_CONNECTIONS_PER_HOUR 0 MAX_UPDATES_PER_HOUR 0 MAX_USER_CONNECTIONS 0 ;

Then protect the file : owned by the user and group your zabbix agent is running on behalf of and proper chmod :

chown zabbix:zabbix userparameter_mysql.conf
chmod 400 userparameter_mysql.conf

1 2	chown zabbix:zabbix userparameter_mysql.conf chmod 400 userparameter_mysql.conf

You can also set a home dir for zabbix user, and set user and password in ~/.my.cnf

Samba

See : www.zabbix.com/forum/showthread.php?t=1995

Weekly and monthly Screen summary by e-mail

You can find a nice Perl script that send an e-mail with all of your favorites Zabbix screen here : www.zabbix.com/forum/showthread.php?t=20312

To make it work as, for example, /usr/share/zabbix-scripts/graphreport.pl you need the following :

apt-get install curl
mkdir /usr/share/zabbix-scripts
/usr/bin/perl -MCPAN -e 'install DateTime'
/usr/bin/perl -MCPAN -e 'install MIME::Lite'
chmod 700 /usr/share/zabbix-scripts/graphreport.pl

apt-get install curl

mkdir /usr/share/zabbix-scripts

/usr/bin/perl -MCPAN -e 'install DateTime'

/usr/bin/perl -MCPAN -e 'install MIME::Lite'

chmod 700 /usr/share/zabbix-scripts/graphreport.pl

You need also to adapt parameters at the begening of the file regarding Zabbix user and database

In addition, if you are using Zabbix 2.2.1, change the line 62 (“$cmglogin..”.) by :

my $cmdLogin = `curl -s -c $cookie -d 'name=$login&amp;password=$pass&amp;enter=Sign%20in' $zabbix/index.php`;

1	my $cmdLogin = `curl -s -c $cookie -d 'name=$login&password=$pass&enter=Sign%20in' $zabbix/index.php`;
